Schmitt Premium cables are manufactured true to the original in Austria: Absolutely accurate fit and handmade in the highest quality. Fast machine manufacturing processes to save costs are deliberately not used here.
The inner cables are made from special cable steel (and not from the today mostly used brittle stainless steel). Therefore, the Schmitt Premium cables do not break as quickly as those from mass production.
Schmitt cables for classic vehicles are manufactured in the same design as it was standard at the time of production of the vehicles. Thus, for all fans of classic vehicles, a cable true to the original is used here. Since an inner cable manufactured in the old way tends to rust, it is lubricated with an Interflon high-performance fluid grease for life.
OEM number for comparison purposes only: 910.8.04.001.2
Dimensions:
Overall length: 78cm
Sheath length (incl. caps): 61cm
Stranded wire diameter: 3mm
Sheath diameter: 6mm
End cap length: 21.5mm
End cap diameter: 6-8mm
Nipple diameter: 7mm
Nipple length: 22mm
Clevis length: 55mmn, Width: 15mm
Width (bore hole to bore hole): 17mm
Bore hole diameter: 6.5mm
Threaded bolt length (w/ hexagonal adjusting screw): 40mm
Thread length: 29mm
Nut: M7
Rubber grommet: 6mm
Outer diameter: 18mm
Inner diameter: 10mm
Thickness: 6.5mm
