Flywheel -BGM PRO Electronic- Lambretta GP, DL 52212

bgm PRO fan wheel completely developed and manufactured in Germany. This is a one-piece fan wheel without rivets and screws. Technology of the 21st century in almost original optics and design. The fan wheel has been successfully tested up to 24.000 rpm and gives with the bgm V3 ignition base plate the highest alternator performance.

Features:

Moment of inertia 6240 kg mm² (-5%)

Weight dl/GP 2025 Gramm

Weight LI/SX 2051 Gramm

Balance less than 100 gmm

Burst test 24.000 rpm

Improved cooling effect

The fan wheel is a completely new design, which has been built around the existing bgm ignition components. The goals were highest reliability and a strong alternator performance.

To ensure the highest possible reliability, the cone is neither screwed nor riveted, but cast in place. Each cone is checked and reworked after casting to ensure a perfect fit to the crankshaft.

We specify the weight of the fan wheel, but this is secondary in relation to the engine running. Here the achieved moment of inertia is the decisive value. In other words, how and where the weight is distributed around the circumference of the circle.

The balancing factor is the next interesting factor. Here we reach a value which is also used in real motorsport. Each fan wheel is individually brought to at least this value. This is the best value ever achieved for a Lambretta fan wheel.

The fan wheel has passed the burst test up to 24,000 rpm without any damage. Of course the bgm PRO pole wheel can also be used with all components based on the original Ducati design with 6 coils. (Such as Indian, AF, AFR, Vespa components.) However, should problems occur here, the height of the pickup may have to be adjusted depending on the combination of components. We are happy to give you technical support.

_{AI-translation}
