LED Tube T8 EM 23.1W for Fixtures

Product no.: BTS-162.00.86

LED Tube T8 EM 23.1W for Fixtures

LEDVANCE LED TUBE T8 EM

• LED tubes for electromagnetic ballasts (KVG/WG), splinter protection.
• Product features: LED replacement for conventional T8 fluorescent lamps with G13 base in KVG luminaires or on mains voltage.
• Low flicker according to EU 2019/2020 (SVM = 0.4 / PstLM = 1).
• Single and tandem operation on conventional ballast (0.6 m version).
• Glass lamp tube with splinter protection for applications e.g. in the food industry.
• Mercury-free and RoHS-compliant.
• Homogeneous illumination.
• Protection class: IP20.

Product advantages:

• No sagging thanks to glass tube.
• Simple, quick and safe lamp replacement without rewiring.
• Energy savings of up to 66 % (compared to T8 fluorescent lamps).
• Full brightness without warm-up phase, therefore ideally suited in combination with sensors.
• Very high switching stability.
• Also suitable for operation at low temperatures.

Areas of application:

• General lighting in ambient temperatures of -20...+50°C.
• Lighting in industrial production.
• Traffic zones and corridors.
• Supermarkets and department stores.
• Industry.

Technical features:

• Suitable for operation with low-loss and conventional ballasts.

Technical data

Color temperature: 4000 KColor rendering index CRI: 80-89Color consistency (McAdam ellipse): SDCM5Protection class (IP): IP20Length: 1513 mmVoltage type: ACNominal voltage: 220 VPower factor: 0.90Photobiological safety according to EN 62471: RG0Base: G13Diameter: 26.70 mmLamp luminous efficacy: 160 lm/WLight color according to EN 12464-1: neutral white 3300 to 5300 KGlass/cover finish: frostedAverage rated service life: 60000 hRated current: 102 mAWeighted energy consumption in 1.000 hours: 24 kWhLamp wattage: 23.1 WLuminous flux: 3700 lmLamp designation: T8Min. Number of switching operations: 200000Rated luminous flux according to IEC 62612: 3700 lmEnergy spectrum: A - GEnergy efficiency class according to EU Directive 2019/2015: C

Manufacturer Nr.: Ledvance 35021212

EAN: 4099854037030

Price:

42,34 EUR

19 % VAT incl. excl. Shipping costs
