Steering wheel remote control adapter 20Pin/32Pin Dacia /Fiat / Nissan / Opel / Renault / Smart

Retain the original steering wheel remote control functions when replacing the factory radio with a retrofit radio.Depending on the vehicle equipment and the range of functions and software of the retrofit device, individual operating functions may be omitted or replaced by other functions.Compare the adapter plugs shown with those in your vehicle and make sure that they match visually and technically.Please also check whether one of the specified original factory radios was installed in your vehicle.Before final installation, check the vehicle functions, vehicle settings and steering wheel remote control for proper functioning.

Note:analogConnection: 20 pin / 32 pin Nissan connectorCheck dip switch position (see BDA)Vehicles with Visteon Anatel RO13-X07 2-DIN OEM deviceVehicles with Browse 1-DIN OEM device with 2 x black rotary knobVehicles with radio preparation

Vehicles without OEM navigation

Vehicles 2017>:red +12V ignition current terminal 15 fuse box fused > if necessaryVehicles 2017>:Interface red +12V ignition current terminal 15 fuse box fused > if necessary

Vehicles Nissan Primastar (4/J4) 09/2021 - 2023 with PDC additionally:Warning tone interface PDC Nissan Primastar/Renault Trafic > Part: 42cxpdc-trafic3-1

Vehicles Renault Trafic Renault Trafic III (J/JL) 09/2019 - 03/2022 with PDC additionally:Warning tone interface PDC Nissan Primastar/Renault Trafic > Part: 42cxpdc-trafic3-1

Diagnostic LED:blue constant > Interface active +12V power supply ignition current presentred > Steering wheel remote control button function recognized

Suitable for the following vehicles:

DaciaDacia Dokker (SD) 03/2017 - 11/2020*Dacia Dokker Stepway (SD) 03/2017 - 11/2020*Dacia Duster (SR) 01/2018 - 07/2021*Dacia Lodgy (SD) 03/2017 - 01/2022*Dacia Lodgy Stepway (SD) 03/2017 - 02/2022*Dacia Logan MCV (SD) 11/2016 - 09/2020*Dacia Logan MCV Stepway (SR) 05/2017 - 09/2020*Dacia Sandero (SD) 11/2016 - 09/2020*Dacia Sandero Stepway (SD) 11/2016 - 09/2020*

FiatFiat Talento (ZAF 296) 07/2016 - 10/2021*/**

NissanNissan NV300 (4/J4) 11/2016 - 06/2019*/**/***Nissan NV300 (4/J4) 06/2019 - 09/2021*/**/***Nissan NV300 (4/J4) 05/2021 - 09-2021*/**/***Nissan NV400 (M) 08/2014- 07/2020*/**/***Nissan NV400 (M) 07/2020 - 12/2021*/**/***Nissan Primastar (4/J4) 09/2021 - 2024**/****

OpelOpel Movano B (X62) 10/2013 - 09/2019*/**Opel Movano B (X62) 10/2019 - 08/2021*/**Opel Vivaro B (X82) 06/2014 - 01/2019*/**

RenaultRenault Captur (R) 06/2013 - 03/2017*Renault Captur (R) 03/2017 - 12/2019*Renault Express (RJK) 05/2021 - 2023****Renault Kangoo (W) 03/2013 - 12/2020**Renault Kangoo Rapid (W) 05/2013 - 05/2021Renault Kangoo Z.E. Rapid (W) 05/2013 - 06/2022Renault Kangoo III (RJK) 05/2021 - 2023**Renault Master III (M) 09/2014 - 08/2018**Renault Master III Z.E. (M) 06/2018 - 06/2020**Renault Master III (M) 10/2019 - 2024**Renault Trafic III (L/JL) 09/2014 - 07/2019*/**Renault Trafic III (L/JL) 09/2019 - 03/2022*/**Renault Trafic III (L/JL) 05/2021-2024**/****Renault Twingo (AH) 09/2014 - 04/2019*/**

SmartSmart ForTwo (453) 11/2014 - 06/2019*

The following signals are provided:

Reimport vehicles or vehicles with different software may be incompatible in terms of functions.Steering wheel remote control

*Vehicles with Visteon Anatel RO13-X07 OEM device without CAN bus**Vehicles with Browse 1-DIN OEM device with 2 x black rotary knob**Vehicles with radio preparation***Vehicles with 1-DIN OEM device****Vehicles with Browse Visteon 1-DIN OEM deviceConnection cable for the following radio manufacturers:

Multilead various devices > Article: 42arc100Alpine 3,5mm jack connection > Article: 42arc101Blaupunkt 2010> 3.5mm jack connection > Article: 42arc107Blaupunkt 2010> Key1 / Key2 / (GND) connector > Article: 42arc000China HU Key1 / Key2 / (GND) connector > Article: 42arc000Clarion 3.5mm jack connection > Article: 42arc104Digital Dynamics single cable connection > Article: 42arc108ESX Key1 / Key2 connection > Article: 42arc000JVC 3.5mm jack connection > Article: 42arc104JVC single cable connection > Article: 42arc105Kenwood single cable connection > Article: 42arc105Kenwood 2017> 3.5mm jack connection > Article: 42arc107Kenwood 2020> Key1 / Key2 / GND connection > Article: 42arc000Pioneer 3.5mm jack connection > Article: 42arc107Pioneer AVH/DMH/SPH 3.5mm jack connector > Article: 42arc1072Snooper Key1 / Key2 connection > Article: 42arc000Sony 3.5mm jack connection > Article: 42arc107XZent single cable connection > Article: 42arc108Zenec single cable connection > Article: 42arc108

General installation instructions:

Check:1: Check all operating functions and vehicle setting functions of the OEM device2: Disassembly of the OEM device without voltage3: Check all interface connections for correctness and continuity without voltage

Connection and connection sequence:1: De-energize the settings and hardware configuration of the interface2: Check the configuration of the radio connection cable3: Connect the radio connection cable according to the operating instructions for the retrofit device4: Connect all other connections according to the operating instructions for the retrofit device5: Connect the overall installation to the vehicle with live connection last6: Software configuration of the interface according to the instructions in the article text and in the BDA7: Configuration of the retrofit device according to the operating instructions for the retrofit device steering wheel remote control/camera/FSE/antenna phantom power and others8: Function test steering wheel remote control and vehicle

Changes to the hardware configuration of the interface and the radio connection cable:1: Make changes without voltage2: Connection after change see above 5 to 8

If the interface or the vehicle malfunctions:1: Reset to the OEM device2: Operate OEM device3: Establish CAN bus quiescence4: Check the hardware configuration of the interface5: Connection after CAN bus rest see above 5 to 8

Connections, connection changes, alternative connections, connections of loose cables or connection extensions of loose cables specified in the information text or the operating instructions are for guidance and information purposes only for trained specialist personnel.

Additional connections, changes to the cable configuration of the wiring harness or the use of alternative connections or connection extensions:1: Connections and modifications must only be carried out by trained specialist personnel2: Connections and modifications must be checked for any manufacturer approvals or manufacturer warranty conditions that may be affected by the modifications before connection3: Connections and modifications must be checked for function and correctness before connection by measuring and comparing with the vehicle's cable assignment diagram4: Connections and modifications are carried out under your own responsibility without guarantee of function5: Connections and modifications are carried out under your own responsibility without guarantee of damage to the vehicle, the retrofit device or the interface6: Modifications to the pre-assembled wiring harness may invalidate the product warranty

Manufacturer Nr.: ACV

EAN: 4026724344653
